Every exhibit makes one point, carries its unit and its source, and can be checked on its own. The exhibits below use illustrative data.
-
Exhibit 1 / Report
Illustrative data
In this illustrative series, one week falls outside the upper control limit
Deviations recorded per week, one site, 20 weeks, count; center line and limits from the same series
Note: Values are placeholders chosen to demonstrate the exhibit format. CL is center line; UCL and LCL are upper and lower control limits. The signal in week 12 is marked with a filled marker and a label.
Source: Illustrative data for layout purposes only; not research findings.
From: Control every day
PermalinkData table
In this illustrative series, one week falls outside the upper control limit (Deviations recorded per week, one site, 20 weeks, count; center line and limits from the same series) Category Value W1 6 W2 8 W3 5 W4 7 W5 9 W6 6 W7 7 W8 5 W9 8 W10 6 W11 7 W12 15 W13 7 W14 6 W15 8 W16 5 W17 7 W18 6 W19 8 W20 7 -
Exhibit 1 / Definitions
Illustrative data
In this illustrative register, deviations outnumber the other three record types
Quality records opened by type, one site, one quarter, count
Note: Values are placeholders chosen to demonstrate the exhibit format. Each record type is counted separately.
Source: Illustrative data for layout purposes only; not research findings.
From: Nonconformity, deviation, observation and finding mean different things
PermalinkData table
In this illustrative register, deviations outnumber the other three record types (Quality records opened by type, one site, one quarter, count) Category Value Deviations 42 Nonconformities 18 Audit observations 11 Audit findings 4 -
Exhibit 1 / CAPA
Illustrative data
In this illustrative CAPA, the effectiveness check takes longer than the action it verifies
Median days in each CAPA stage, one site, one year, days
Note: Values are placeholders chosen to demonstrate the exhibit format. Stages are shown in process order. CAPA is corrective and preventive action.
Source: Illustrative data for layout purposes only; not research findings.
PermalinkData table
In this illustrative CAPA, the effectiveness check takes longer than the action it verifies (Median days in each CAPA stage, one site, one year, days) Category Value Investigation 21 d Action 34 d Effectiveness check 58 d Closure 6 d -
Exhibit 1 / Inspection readiness
Illustrative data
In this illustrative site, more than four in ten open records are older than their target closure time
Open quality records by age band, one site, at one date, count; illustrative target closure time 60 days
Note: Values are placeholders chosen to demonstrate the exhibit format. Age bands are in natural order. Bands past the 60-day target are shown in Forest: 23 of 54 open records.
Source: Illustrative data for layout purposes only; not research findings.
PermalinkData table
In this illustrative site, more than four in ten open records are older than their target closure time (Open quality records by age band, one site, at one date, count; illustrative target closure time 60 days) Category Value Under 30 days 12 30 to 60 days 19 60 to 90 days, over target 14 Over 90 days, over target 9
